WhisperKOOL Quantum 12000 Split Ducted Wine Cooling System

$10,138.00

Notify me when back in stock

Description

At Wine Cooler Collection, we understand that your wine collection is your pride and joy. That's why we're proud to offer you the WhisperKOOL Quantum 12000 Split Ducted Wine Cooling System - the ultimate solution for cooling your wine cellar and ensuring that your wine stays in perfect condition.

This incredible cooling system comes with interchangeable evaporator airflow panels, giving you complete control over the direction of the airflow. This means that you can direct the airflow exactly where you need it, ensuring that your wine is cooled evenly and stays at the perfect temperature.

The WhisperKOOL Quantum 12000 also comes with a pump system to remove excess condensation, ensuring that your wine stays dry and free from any potential damage. And with both standard and 24V thermostat options available, you have the flexibility to choose the option that works best for you.

The system also boasts electro-fin coated coils, which offer unparalleled protection against outgassing that occurs in cellars. This means that you can rest assured that your wine will be protected from any potential damage that could be caused by outgassing.

And with the option to place the condensing unit outdoors with the purchase of exterior housing, you can keep your wine cellar separate from your living space, ensuring that your wine stays in perfect condition.

The WhisperKOOL Quantum 12000 also features a 220V High Efficiency (H.E.) Condenser, which ensures that your wine is cooled quickly and efficiently, keeping it at the perfect temperature for optimal aging and flavor development.

At Wine Cooler Collection, we're committed to providing you with the very best in wine storage solutions, and the WhisperKOOL Quantum 12000 is no exception. Don't settle for anything less than perfection when it comes to your wine collection.

Product Video

Features
  • Interchangeable evaporator airflow panels
  • Includes a pump system to remove access condensation
  • Standard and 24V thermostat options available
  • Electro-fin coated coils for protection against outgassing that occurs in cellars
  • Condensing unit can be placed outdoors with the purchase of exterior housing
  • 220V High Efficiency (H.E.) Condenser (Click to learn more)

Note: A qualified HVAC-R technician is required for the installation of the Quantum 12000. Failure to have the system installed by a qualified technician will void the warranty.

*PLEASE NOTE: WhisperKOOL does not provide a smart thermostat. By selecting the 24V Thermostat Conversion Kit, you have acknowledged that the system will not be built with the standard WhisperKOOL control or liquid measuring bottle probe. You will have to source and purchase your own 24V smart thermostat to run the equipment.

Specs

dBA: 52
Dimensions: 31.18"L x 10.75"W x 23.25"H
Condensing Unit HP: 1.5HP
Voltage Rating: 220V (15-amp dedicated circuit required)
Weight (lbs): 84
Amps: LRA 23.6, RLA 5.76, FLA 6.6
Line Set: Liquid line 3/8” OD; Suction line 5/8” OD (less than 50 ft.), 3/4” (greater than 50 ft.)
Installation: Condensing unit can be installed up to 100 line feet from the evaporator unit.
Temp. Delta: Can maintain a 55°F cellar temperature with up to 120°F condenser air intake temperature

3D Tour

Resources

220V Copeland Condenser / H.E Owner's 220V Manual

Installation Manual / H.E. Installation Manual

Owner Manual – with 24V Thermostat Conversion Kit

Warranty

Products purchased from Wine Cooler Collection are covered by our supplier’s exclusive warranty

A limited 2-year product warranty is offered with all split systems. While the warranty starts at the date of purchase, this warranty is not activated until a Product Warranty Checklist has been submitted and approved by WhisperKOOL.

Submit Checklist Online
